Crystal Engineering NV-4AA-100PSI-3KPSI nVision Dual Sensor 100 PSI / 3K PSI
Crystal Engineering NV-4AA-100PSI-3KPSI accelerates high-precision differential monitoring by replacing mechanical recorders with a handheld 100/3,000 PSI interface that delivers 10 readings per second for rigorous relief valve testing.
- Display Spec: High-speed graphical capture
- Measurement Precision: 0.025% metrology grade accuracy
- Digital Interface: Dual module differential mode
- Thermal Range: IP67 submersible portable design
- Field Usage: 200 bar manifold audit
Compliance: NIST traceable metrology certified.
$2,621.00
In Stock
| Brand | Crystal Engineering (AMETEK) |
| MPN | NV-4AA-100PSI-3KPSI |
| Model SKU | nVision Reference Pressure Recorder (100 PSI / 3,000 PSI) |
| Measurement Range | Dual Sensor: 100 PSI (7 bar) and 3,000 PSI (200 bar) |
| Metrology Performance | 0.025% of Reading Accuracy; replaces mechanical recorders |
| Differential Mode | High-precision differential monitoring with metrology grade results |
| Environment | Handheld portable design; submersible to 3 feet (IP67) |
| Sampling Speed | 10 readings per second fast capture rate for relief valve testing |
| Compensation | Temperature compensated accuracy from -20 to 50°C |
| Warranty | 1-Year Manufacturer Warranty |
| Each Unit Includes | nVision Unit, Dual 100/3K Modules, and NIST Documentation |
