TTI PM305-0350-K Pressure Calibrator 5000psi 350bar
TTI PM305-0350-K resolves medium-high pressure field validation hurdles via a 316L stainless steel sensor and IP65 protective housing, delivering ±0.05% FS accuracy for 5,000 psi signal verification.
- Display Spec: Digital 0.1 psi resolution with RS-232 logging
- Precision Metric: ±0.05% Full Span (FS) accuracy
- Digital Interface: RS-232 Data Logging Integration port
- Power Range: 9V Alkaline battery (0 to 5,000 psi)
- Field Usage: Field-ready signal integrity verification
Compliance: NIST Traceable and ISO/IEC 17025.
$2,354.00
In Stock
TTI PM305-0350-K Pressure Calibrator Technical Specs
| Brand | TTI (Transcat) |
| Model SKU | PM305-0350-K (5,000 PSI / 350 Bar) |
| Country of Origin | United States |
| Specific Operating Range | 0 to 5,000 psi (350 bar) |
| Accuracy Class | ±0.05% FS (Full Span) |
| Resolution | 0.1 psi; 0.01 bar |
| Piston-Cylinder / Sensor Material | 316L Stainless Steel |
| Temperature Compensation | 0°C to 50°C (Digital Characterization) |
| Media Compatibility | Hydraulic Oil, Non-corrosive Gases |
| Gravity Correction | N/A (Electronic) |
| Data Logging Capacity | RS-232 Data Logging Integration |
| Interface & Port Type | 1/4" NPT Male |
| Power & Battery Life | 9V Alkaline Battery; 100 hours |
| Safety & Protection | IP65 Protective Housing; 110% Overpressure Limit |
| Compliance | NIST Traceable, ISO/IEC 17025 |
| Warranty | 1-Year Standard |
| Industrial Application | Field-ready Signal Integrity verification for medium-high pressure systems. |
